TS (Lightweight Range)

TS1


TS2


TS3


TS4


TS5


TS6


TS (Lightweight Range) Retro Fit

TS9


TS10


TS11


TS12


TS (Lightweight Range) Retro Fit - DDA Compliant

TS15


TS16


TS17


TH (Heavyweight Range)

TH1


TH2


TH3


TH4


TH5


TH6


TH (Heavyweight Range) - DDA Compliant

TH7


TH9


TH10


DDA Compliant


Retro Fit


Angles & Additional Profiles

Multi Angle Lengths


Height adjustable side angle lengths for landings etc

Pre Formed Angles

Height adjustable preformed angles for stairs. Universal for left or right handed use

Height adjustable preformed angles for stairs. Universal for left or right handed use

Nap Tims


Nap trims clip on to the rear of the TH range to accommodate thicker carpets with underlay for instance. Available punched or unpunched

Mitre Curves


Pre cut pieces to form a neat edge on curved bottom steps

Customer template required

Synbrass Gold Effect


Synbrass gold effect finish available in selected profiles

TS1 / TS3 / TS9 / TS10 / TS11 / TS12

TH1 / TH3 / TN1 Nap Trim


Insert Colours


Range of 16 colours to suit most interior decors

stairnosings uk

Products

Profile Selection

To decide which profile is best for your installation, please consider the following..


Check the profile of the stair, does it have a rounded front, square front or raked back shape?


Raked back stairs taper back at an 83 degree angle to give more tread area on the step. It may look square, but just double check, if a square fronted nosing is fitted in this instance, you will find that this will leave a finger sized gap behind, which is not ideal.


Next, consider the amount of foot traffic. Is it a heavy use staircase, if so, you may want to consider a double channel profile, although single channel profiles will suit in many cases.


Which type of floor covering is being installed? Carpet will usually require a profile from the TH range unless the carpet is very thin. For thicker floor coverings, you may have to consider the TN1 Nap Trim which will clip onto the back of any of the TH range to accommodate.


For vinyls, the TS range is suited for these. Standard TS is designed for floor covering to fit to the back edge. The popular Retrofit profiles have a diminishing back edge, so these can be installed on top of hard floor coverings or bare stairs.


Another thing to consider is does the staircase need to conform to the DDA regulations. If so, then look at the DDA profiles which have a 55mm drop.


Colour choice can be important, the LRV (Light Reflectance Value) of the floor covering and the insert colour ideally need to differ by 30 points. Check out our download section for the coloured insert LRV values.


The final thing is the installation method, again, details can be found in our download section.

Check out the chart of products

Lets have a look and see which profile will

suit your job

Product chart
